DC5V APA102C / SK9822 Addressable LED Strip 60 LEDs/m

📌 1️⃣ Product Overview

Product Overview

This DC5V addressable LED strip supports both APA102C and SK9822 protocols, offering flexible addressable pixel control with 60 LEDs per meter. The dual protocol compatibility ensures broader controller support and higher refresh rates, ideal for dynamic RGB lighting effects.

Its flexible PCB design allows curved installation and creative layouts for signage, architectural accents, event decor, and decorative installations.

📌 2️⃣ APA102C vs SK9822 — Technical Highlight

APA102C vs SK9822 Addressable Control

Both APA102C and SK9822 are high-speed digital LED protocols with separate data and clock lines, delivering faster refresh rates and smoother dynamic effects than single-wire solutions.

• APA102C: High refresh, stable performance, widely supported

• SK9822: Compatible with APA102C footprint, excellent color syncing

Dual protocol support increases compatibility with a wider range of controllers and software.

📌 3️⃣ Application Scenarios

Application Scenarios

This addressable LED strip is perfect for:

• Retail and promotional signage

• Architectural accent lighting

• Stage and event decorative effects

• Interactive installations

• Creative dynamic RGB applications

Individual pixel control enables chasing, gradients, animations, and color sequences.

Item	Specification
Product Name	DC5V APA102C / SK9822 Addressable LED Strip
LED Type	RGB Fully Addressable LEDs
Protocol	APA102C / SK9822 Dual Protocol
LED Density	60 LEDs per meter
Operating Voltage	DC5V
Power Consumption	18W
PCB Width	(0mm
Cuttable	Yes (per pixel segment)
Viewing Angle	120°
Waterproof Rating	IP20 / IP65 / IP67 (optional)
Lifetime	≥ 50,000 hours
Working Temp	-20℃ to +60℃
Storage Temp	-30℃ to +80℃
