IP67 DC24V 48LEDS 16Pixels UCS1912 Digital RGB LED Outdoor Tube Light
Beam Angle:180 degree
LED Quantity:48pcs/m
Pixel QTY:8 pixels/m
IC CHIP:UCS1912
LED Power Consumption:11.52W/m (max)
Size (mm):1000x50x45 mm (L*W*H)
Input Voltage:DC24V
Shell color:Transparent steak cover / Milky white cover
Aluminum profile:Sliver white / Black
Certification:CE, RoHS
Working temperature :-20℃-60℃
Storage temperature: -30℃-80℃
1. Digital pixel led guardrail tube is widely used for outdoor application bridge, road, advertisement sign decoration.
2. Support numerous color changing effects. 48pcs super bright smd 5050 rgb leds per meter.4pcs UCS1912 IC chip per meter, IC UCS1912 is 12channels, one IC control 4 RGB segment individually, that's 16pixels/m.
3. The tube is designed with high quality aluminum case to provide an adequate heat sink to ensure an efficient, long and bright LED life. Epoxy glue coverd on top of the file for waterproof.Strong shell has 3 color options : milky white, translucence, transparent.The whole bar is waterproof IP67.
4. Each bar has a pair of good quality 3Pin female/male connector for signal transmission.The length of connector 15cm, 3pin 20AWG copper wire in white /black PVC cable.
5. Low voltage 12V DC input, don't over 13V, otherwise the tube will easily be destroyed.
6. The led bar did not include any T type cable for power feeding. It requset to purchase seperately, and we recommend use T type cable for every 4M or 5M.
7. Aluminum clips included (2pcs clips per meter) for installation.
8. Protocol : SD card controller, Artnet, DMX controller, Ardunio and others.
