How to Choose a 10mm Digital Pixel Curtain for Displays and Decorative Grids
A B2B guide to selecting a DC5V 10 mm RGB digital pixel-string curtain by grid pitch, viewing distance, control mapping and installation planning.
Project image and viewing distance
A pixel curtain is selected for the image its physical grid can create. A grid that looks smooth from a lobby entrance may look sparse from a closer walkway, while a very tight grid can add unnecessary point count and control work.
Published configuration
The published product page identifies a 10 mm RGB digital pixel-string curtain with DC5V input. It does not publish pixel pitch, W/m, controller capacity, signal distance or protection rating. Those values must be set from the final layout rather than inferred from the product name.
Power and voltage-drop planning
Because DC5V is the published input, power distribution deserves early attention. No published consumption is available, so do not estimate cable load from appearance. Fix the total points, string arrangement and published final consumption first; then divide the installation into practical circuits and verify loaded voltage at the far end.
Control architecture
This is a programmable pixel-string product. Confirm the final control IC or protocol, controller compatibility, data direction, pixel order, connector pinout and content mapping before sampling. Pixel strings use a cascade data path unless the final selected system states another architecture; do not assume a DMX address plan.
Installation and protection
The curtain is more than light points: suspension, tensile load, cable exits, strain relief, maintenance access and field joints affect the finished grid. The page does not publish an IP rating, so exposure and protection construction require final product and site confirmation.
Quick selection table
| Project condition | Selection guidance |
|---|---|
| A recognisable image is required | Set the physical grid pitch from the viewing distance and test a sample area. |
| Broad colour movement | A more open grid can be suitable when individual points need not describe fine shapes. |
| Close viewing | Evaluate visible point spacing and content detail before freezing the curtain layout. |
| DC5V distribution | Obtain published W/m or W/string and calculate circuits from the final quantity. |
| Programmable effects | Confirm controller compatibility, data direction and pixel mapping for the final configuration. |
| Installed curtain | Plan support, cable routing, service access and field connections with the grid. |
Where the configuration fits
LIKELIGHT can be evaluated for decorative grids, digital curtains and low-resolution pixel images where the project benefits from a visible point structure. It is not a substitute for a high-resolution video display. The most useful decision is whether the selected grid pitch gives the intended image at the real viewing distance.
| Model | 10 mm RGB digital pixel-string curtain |
|---|---|
| Published configuration | DC5V |
Information before quotation
Before quotation, send the layout, quantities by zone, viewing distance, target effect, installation environment, controller information, cable direction and sample or delivery requirement. These inputs are used to evaluate the product as part of a complete project system.
