DC5V WS2813 dmx5050 60 pcs pixels/m addressable Digital LED tube light
Voltage:DC5V
Pixels/m:60pixels/m
Size (mm):width 20mm x height 20mm
Length:0.5m, 1m, 1.5m, 2m are workable
IP Level:IP67
Shell:PC Shell+ Aluminum Base
Cover type:Transparent/milk white
IC Type:WS2813
Beam angle:180 degree
Certification:CE, RoHS
Working temperature :-20℃-60℃
Storage temperature: -30℃-80℃
1. The Digital DMX RGB led bar is standard WS2813 protocol, WS2813 IC chip included.
2. Aluminum case with 100% glue injection waterproof for outdoor using , with tempering glass cover.
3. One meter has 60pcs super bright 5050 RGB LED, each LED Covered by a optic lens, projection angle can be adjusted by lens angle, the lens angle can be 180°.
4. Rigid PCB, 60leds/m, 60pixels/m.
5.4pin high quality waterproof connectors on both end of the bars , 15cm wire length and can customised.
6. Aluminum case color options : black/ silver White.
7. Each bar included 2pcs moveable aluminum holder for installation.
8. Low voltage DC5V input, don't over 5V, otherwise you can destory the whole led wall washer.
9. The led bar didn't attach any T cable connectors for power feeding, it request to purchase seperately. And we recommend every 4M bar supply power.
