This guide uses the published Like Light configuration as a technical starting point. It explains what a project buyer should confirm before sampling, procurement and installation.
Get a QuoteView Product Details
Published specification
| Published specification | L-C-1818 |
|---|---|
| LED / color | SMD3535 RGB LED |
| Voltage | DC12V |
| Power | 0.72W |
| Control IC | UCS5603 |
| Pitch | 55mm pitch or customized |
| IP | IP67 |
| Environment | -20C to 60C |
Engineering design review
The table records the published configuration. Final optical performance, run length and installation arrangement must be approved against the project drawing rather than inferred from a catalogue image.
Treat the published table as a design baseline, not a released installation drawing. The engineering decision is whether the specified optical output, pitch and physical format suit the viewing distance, mounting geometry and service strategy. Like Light can review the project drawing and return the configuration items that must be frozen before sampling.
Control and signal boundary
Only the published IC or control information should be used for controller selection. Confirm protocol, data direction, pixel grouping, connector pinout and port loading before production.
An LED package identifies the light source; it does not by itself identify a control IC or protocol. Confirm the controller model, protocol, pixel grouping, data direction, connector pinout and controller-port loading from an approved drawing. This prevents a sample that lights correctly but cannot be commissioned with the project control system.
Power distribution review
Calculate feed points and cable from the released quantity, length and full-load condition. Measure voltage at the far end under load during commissioning; nominal supply voltage alone is not acceptance evidence.
Use the published maximum load only as the starting point for a circuit calculation. Final feeder quantity, cable cross-section, injection points and protection devices depend on the approved length, quantity, effect programme and measured voltage at the far end under load. Do not release a long run from a nominal supply-voltage reading alone.
Mechanical and IP boundary
Confirm mounting orientation, cable exit, end treatment, field joints, drainage, corrosion exposure and replacement access. A fixture IP rating does not automatically validate the installed assembly.
The stated IP option is not a complete site-waterproofing design. Review mounting orientation, cable exit, end treatment, joint method, drainage path, corrosion exposure and access for replacement. An outdoor installation should be accepted as a complete assembly, not by the fixture rating alone.
How to use the published data
The published product data identifies the configuration that can be evaluated first. It does not replace a project drawing or a released electrical plan.
A practical review starts with the visual target and installation geometry, then confirms control, power, cable routing and environmental protection as one coordinated system.
Project information required before quotation
- Project drawing and mounting direction.
- Viewing distance and target visual effect.
- Controller, protocol and connection information.
- Final voltage, run length and quantity.
- Cable exit, connector and permitted field joints.
- Outdoor exposure, drainage and IP target.
- Power distribution and voltage-drop test plan.
- Sample, delivery date and acceptance method.
Commissioning method
Commission one circuit at a time. Compare installed product, cable direction and connection with the approved drawing before energizing.
Run the intended effect under the expected load. Verify visible output, communication and far-end voltage; document the circuit identity, controller file and test result for maintenance.
Factory and site acceptance
Check approved model, visible output, connector continuity and voltage under load against the signed sample or drawing. Keep a circuit and address record for future replacement.
Before shipment, inspect the approved model, visible output, connector continuity and full-load electrical condition against the signed sample or drawing. At site, energize by circuit, record the final address map where applicable, check voltage under load and retain a replacement reference for maintenance.
OEM order freeze
Freeze dimensions, cable and connector, protection construction, control interface, sample revision, labels, packaging and acceptance criteria before the production release.
A usable OEM order freeze records more than colour and quantity: it includes dimensions, lengths, cable specification, connector, ingress-protection construction, approved control interface, sample revision, label or packaging requirements and acceptance method. This is where supplier capability becomes lower project risk.
Application fit
Select the final configuration from the real viewing distance, mounting geometry, ambient exposure and maintenance plan. Submit these project conditions with the enquiry.
The product page lists application directions, but the final selection must follow the project scene. For a facade or landscape installation, include viewing distance, mounting elevation, ambient exposure, access equipment and desired animation in the enquiry. For hospitality or entertainment use, include control workflow and maintenance windows.
Like Light project support
Like Light offers multiple controller options and can arrange free samples for qualified projects. CE, FCC and RoHS documentation must be confirmed against the exact product configuration and destination-market requirement before the order is released.
FAQ
Can the configuration be customized? Yes. Confirm the published configuration plus the project-specific dimensions, cabling, control interface, protection target and quantity before mass production.
Can Like Light supply a project-specific version? Yes, after the electrical configuration, dimensions, cable exit, connector, protection target and quantity are reviewed. Send the drawing, installation photographs or rendering, controller information and delivery schedule so the quotation can be based on a buildable configuration rather than an assumed one.
